F40-14MX-37-40-SF Powerhouse® HTD Timing Pulley, 4 Teeth, 14M Pitch


Price:
$ 274.12

Description

F40-14MX-37-40-SF Powerhouse® HTD Timing Pulley, 4 Teeth, 14M Pitch

The F40-14MX-37-40-SF is a 4-tooth 14 mm HTD® compatible timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 4mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® HTD pulleys fit drives using HTD® curvilinear belts of the same pitch and width.

Specifications

Specification Value
Part Number F40-14MX-37-40-SF
Teeth 4
Pitch 14 mm HTD® compatible
For Belt Width 4mm
Pitch Diameter 7.0179 in
Outside Diameter 6.908 in
Flange Diameter 7.518 in
Bore Accepts SF bushing (not included)
Face Width 2.125 in
Overall Length 2.125 in
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 12.9 lb
Country of Origin China

Applications

  • HTD curvilinear belt drives on industrial equipment
  • Conveyors, packaging, and warehouse automation
  • Replacing worn pulleys on existing HTD drives

Belt Compatibility

The F40-14MX-37-40-SF runs 14 mm HTD® compatible belts in 4mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The F40-14MX-37-40-SF interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Powerdrive F40-14MX-37-40-SF

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the F40-14MX-37-40-SF pulley?

14 mm HTD® compatible timing belts in 4mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the F40-14MX-37-40-SF replace the Powerdrive F40-14MX-37-40-SF?

Yes. Published interchange data crosses the F40-14MX-37-40-SF directly to the Powerdrive F40-14MX-37-40-SF. Verify dimensions and bore before ordering.

Does the F40-14MX-37-40-SF ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on F40-14MX-37-40-SF?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. HTD® is a registered trademark of Gates Corporation. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
