F50-14MX20-E Powerhouse® MX Timing Pulley, 5 Teeth, 14MX Pitch


Price:
$ 296.92

Description

F50-14MX20-E Powerhouse® MX Timing Pulley, 5 Teeth, 14MX Pitch

The F50-14MX20-E is a 5-tooth 14 mm MX high torque timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 2mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® MX pulleys run on the same high torque drives as Gates Poly Chain® GT® Carbon™ and Continental Synchrochain Carbon belts.

Specifications

Type BF pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number F50-14MX20-E
Teeth 5
Pitch 14 mm MX high torque
For Belt Width 2mm
Pitch Diameter 8.7723 in
Outside Diameter 8.6623 in
Flange Diameter 9.392 in
Bore Accepts E bushing (not included)
Face Width 1.359 in
Overall Length 1.63 in
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 17.63 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • High torque, low speed drives replacing roller chain
  • Air cooled heat exchanger (ACHE) fan drives
  • Oil and gas pumping equipment
  • Material handling and conveyor drives

Belt Compatibility

The F50-14MX20-E runs 14 mm MX high torque belts in 2mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The F50-14MX20-E interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Powerdrive F50-14MX20-E

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the F50-14MX20-E pulley?

14 mm MX high torque timing belts in 2mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the F50-14MX20-E replace the Powerdrive F50-14MX20-E?

Yes. Published interchange data crosses the F50-14MX20-E directly to the Powerdrive F50-14MX20-E. Verify dimensions and bore before ordering.

Does the F50-14MX20-E ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
