F53-14MX-37-40-E Powerhouse® HTD Timing Pulley, 53 Teeth, 14MX Pitch
The F53-14MX-37-40-E is a 53-tooth 14 mm MX high torque timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 4mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® HTD pulleys fit drives using HTD® curvilinear belts of the same pitch and width.
Specifications
| Specification | Value |
|---|---|
| Part Number | F53-14MX-37-40-E |
| Teeth | 53 |
| Pitch | 14 mm MX high torque |
| For Belt Width | 4mm |
| Pitch Diameter | 9.2987 in |
| Outside Diameter | 9.189 in |
| Flange Diameter | 9.687 in |
| Bore | Accepts E bushing (not included) |
| Face Width | 2.125 in |
| Overall Length | 2.125 in |
| Material | Ductile Iron (no sintered or powdered metal) |
| Finish | Black Oxide |
| Weight | 21.6 lb |
| Country of Origin | China |
Applications
- HTD curvilinear belt drives on industrial equipment
- Conveyors, packaging, and warehouse automation
- Replacing worn pulleys on existing HTD drives
Belt Compatibility
The F53-14MX-37-40-E runs 14 mm MX high torque belts in 4mm width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The F53-14MX-37-40-E interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Powerdrive | F53-14MX-37-40-E |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the F53-14MX-37-40-E pulley?
14 mm MX high torque timing belts in 4mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the F53-14MX-37-40-E replace the Powerdrive F53-14MX-37-40-E?
Yes. Published interchange data crosses the F53-14MX-37-40-E directly to the Powerdrive F53-14MX-37-40-E. Verify dimensions and bore before ordering.
Does the F53-14MX-37-40-E ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
Need a quote on F53-14MX-37-40-E?
Houston warehouse, same-day shipping on stock items.
