Description
Representative image shown. Actual product appearance varies by size, bore, and configuration. Refer to the specifications table for exact dimensions of this part number.
QD216-14M-115 Powerhouse® HTD Timing Pulley, 216 Teeth, 14M Pitch
The QD216-14M-115 is a 216-tooth 14 mm HTD® compatible timing pulley. It mounts with an industry-standard bushing, sold separately, machined from cast iron with a black oxide finish, built for 115mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® HTD pulleys fit drives using HTD® curvilinear belts of the same pitch and width.
Specifications

Dimension key for this construction type. Values for this part number are in the table below.
| Specification | Value |
|---|---|
| Part Number | QD216-14M-115 |
| Teeth | 216 |
| Pitch | 14 mm HTD® compatible |
| For Belt Width | 115mm |
| Pitch Diameter | 37.8964 in |
| Outside Diameter | 37.7864 in |
| Bore | Accepts M bushing (not included) |
| Face Width | 5.25 in |
| Overall Length | 5.25 in |
| Construction | Quick Disconnect Hub |
| Material | Cast Iron (no sintered or powdered metal) |
| Finish | Black Oxide |
| Weight | 307 lb |
| Country of Origin | China |
Applications
- HTD curvilinear belt drives on industrial equipment
- Conveyors, packaging, and warehouse automation
- Replacing worn pulleys on existing HTD drives
- Weight-sensitive drives (webbed, lightened construction)
Belt Compatibility
The QD216-14M-115 runs 14 mm HTD® compatible belts in 115mm width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The QD216-14M-115 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Dodge® | P216-14M-115-J |
| Martin | P21614M115-M |
| TB Woods® | P21614M115 |
| Regal Rexnord (Browning®) | B21614M115M |
| Ametric | 14M216QD115 |
| Powerdrive | QD216-14M-115 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What belts fit the QD216-14M-115 pulley?
14 mm HTD® compatible timing belts in 115mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.
Does the QD216-14M-115 replace the Dodge P216-14M-115-J?
Yes. Published interchange data crosses the QD216-14M-115 directly to the Dodge P216-14M-115-J, as well as Martin P21614M115-M, TB Woods P21614M115, Regal Rexnord B21614M115M. Verify dimensions and bore before ordering.
Does the QD216-14M-115 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
