QD37H100 Timing Pulley, 37 Teeth, H Pitch


Price:
$ 157.80

Description

QD37H100 Timing Pulley, 37 Teeth, H Pitch

The QD37H100 is a 37-tooth H (0.500 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 1 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type B1F pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number QD37H100
Teeth 37
Pitch H (0.500 in trapezoidal)
For Belt Width 1 in
Pitch Diameter 5.8887 in
Outside Diameter 5.8347 in
Flange Diameter 6.375 in
Bore Accepts SK bushing (not included)
Face Width 1.312 in
Overall Length 1.312 in
Construction Quick Disconnect Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 7.083 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The QD37H100 runs H (0.500 in trapezoidal) belts in 1 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The QD37H100 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Martin 37H100 SK
TB Woods® 37H100
Regal Rexnord (Browning®) 37H100SK
Mitsuboshi QD37H100
Jason Industrial 37H100SK
Ametric 37H100.SK
Powerdrive QD37H100
Continental (ContiTech) 37H100-SK

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the QD37H100 pulley?

H (0.500 in trapezoidal) timing belts in 1 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the QD37H100 replace the Martin 37H100 SK?

Yes. Published interchange data crosses the QD37H100 directly to the Martin 37H100 SK, as well as TB Woods 37H100, Regal Rexnord 37H100SK, Mitsuboshi QD37H100. Verify dimensions and bore before ordering.

Does the QD37H100 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
