QD40H100 Timing Pulley, 4 Teeth, H Pitch


Price:
$ 142.01

Description

QD40H100 Timing Pulley, 4 Teeth, H Pitch

The QD40H100 is a 4-tooth H (0.500 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 1 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type B1F pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number QD40H100
Teeth 4
Pitch H (0.500 in trapezoidal)
For Belt Width 1 in
Pitch Diameter 6.3662 in
Outside Diameter 6.3122 in
Flange Diameter 6.6 in
Bore Accepts SK bushing (not included)
Face Width 1.312 in
Overall Length 1.312 in
Construction Quick Disconnect Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 8.353 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The QD40H100 runs H (0.500 in trapezoidal) belts in 1 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The QD40H100 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Martin 40H100 SK
TB Woods® 40H100
Regal Rexnord (Browning®) 40H100SK
Mitsuboshi QD40H100
Jason Industrial 40H100SK
Ametric 40H100.SK
McMaster-Carr 6495K522
Grainger 809VL3
Powerdrive QD40H100
Continental (ContiTech) 40H100-SK

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the QD40H100 pulley?

H (0.500 in trapezoidal) timing belts in 1 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the QD40H100 replace the Martin 40H100 SK?

Yes. Published interchange data crosses the QD40H100 directly to the Martin 40H100 SK, as well as TB Woods 40H100, Regal Rexnord 40H100SK, Mitsuboshi QD40H100. Verify dimensions and bore before ordering.

Does the QD40H100 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on QD40H100?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
