QD60-14M-85 Powerhouse® HTD Timing Pulley, 6 Teeth, 14M Pitch


Price:
$ 425.12

Description

QD60-14M-85 Powerhouse® HTD Timing Pulley, 6 Teeth, 14M Pitch

The QD60-14M-85 is a 6-tooth 14 mm HTD® compatible timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 85mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® HTD pulleys fit drives using HTD® curvilinear belts of the same pitch and width.

Specifications

Type D1F pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number QD60-14M-85
Teeth 6
Pitch 14 mm HTD® compatible
For Belt Width 85mm
Pitch Diameter 10.5268 in
Outside Diameter 10.4168 in
Flange Diameter 11.06 in
Bore Accepts F bushing (not included)
Face Width 4 in
Overall Length 4 in
Construction Quick Disconnect Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 52.446 lb
Country of Origin China

Applications

  • HTD curvilinear belt drives on industrial equipment
  • Conveyors, packaging, and warehouse automation
  • Replacing worn pulleys on existing HTD drives

Belt Compatibility

The QD60-14M-85 runs 14 mm HTD® compatible belts in 85mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The QD60-14M-85 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® P60-14M-85-F
Martin P6014M85-F
TB Woods® P6014M85
Regal Rexnord (Browning®) B6014M85F
Jason Industrial P60-14M-85-F
Masterdrive P60-14M-85-F
Ametric 14M60QD85.F
Powerdrive QD60-14M-85
Continental (ContiTech) P60-14M-85-F

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the QD60-14M-85 pulley?

14 mm HTD® compatible timing belts in 85mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the QD60-14M-85 replace the Dodge P60-14M-85-F?

Yes. Published interchange data crosses the QD60-14M-85 directly to the Dodge P60-14M-85-F, as well as Martin P6014M85-F, TB Woods P6014M85, Regal Rexnord B6014M85F. Verify dimensions and bore before ordering.

Does the QD60-14M-85 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on QD60-14M-85?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. HTD® is a registered trademark of Gates Corporation. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
