QD80-14M-170 Powerhouse® HTD Timing Pulley, 8 Teeth, 14M Pitch


Price:
$ 1,077.44

Description

QD80-14M-170 Powerhouse® HTD Timing Pulley, 8 Teeth, 14M Pitch

The QD80-14M-170 is a 8-tooth 14 mm HTD® compatible timing pulley. It mounts with an industry-standard bushing, sold separately, machined from cast iron with a black oxide finish, built for 17mm wide belts. Machined from solid stock, never sintered or powdered metal. Powerhouse® HTD pulleys fit drives using HTD® curvilinear belts of the same pitch and width.

Specifications

Specification Value
Part Number QD80-14M-170
Teeth 8
Pitch 14 mm HTD® compatible
For Belt Width 17mm
Pitch Diameter 14.0357 in
Outside Diameter 13.9257 in
Flange Diameter 14.63 in
Bore Accepts J bushing (not included)
Face Width 7.375 in
Overall Length 7.375 in
Construction Quick Disconnect Hub
Flange Material Steel
Material Cast Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 117 lb
Country of Origin China

Applications

  • HTD curvilinear belt drives on industrial equipment
  • Conveyors, packaging, and warehouse automation
  • Replacing worn pulleys on existing HTD drives

Belt Compatibility

The QD80-14M-170 runs 14 mm HTD® compatible belts in 17mm width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The QD80-14M-170 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® P80-14M-170-J
Martin P8014M170-J
TB Woods® P8014M170
Regal Rexnord (Browning®) B8014M170J
Jason Industrial P80-14M-170-J
Ametric 14M80QD170.J
Powerdrive QD80-14M-170
Continental (ContiTech) P80-14M-170-J

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the QD80-14M-170 pulley?

14 mm HTD® compatible timing belts in 17mm width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the QD80-14M-170 replace the Dodge P80-14M-170-J?

Yes. Published interchange data crosses the QD80-14M-170 directly to the Dodge P80-14M-170-J, as well as Martin P8014M170-J, TB Woods P8014M170, Regal Rexnord B8014M170J. Verify dimensions and bore before ordering.

Does the QD80-14M-170 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on QD80-14M-170?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

Powerhouse® is a registered trademark of its owner. HTD® is a registered trademark of Gates Corporation. All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
