Description
SS3232 Gear, 32 Teeth, 32 DP, 2 Degree PA, Stainless Steel
The SS3232 is a 32-tooth, 32 diametral pitch gear with a 2 degree pressure angle and a 1/4 in minimum plain bore, stainless steel.
$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.
Specifications
| Specification | Value |
|---|---|
| Part Number | SS3232 |
| Teeth | 32 |
| Diametral Pitch | 32 |
| Pressure Angle | 2 degrees |
| Pitch Diameter | 1 in |
| Outside Diameter | 1.063 in |
| Bore | 1/4 in minimum plain bore |
| Face Width | 0.188 in |
| Hub Diameter | 0.5 in |
| Overall Length | 0.437 in |
| Set Screws | 1 x 6-32 |
| Material | Stainless Steel (no sintered or powdered metal) |
| Weight | 0.0507 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- Instrumentation and meter drive trains
- Packaging and labeling machinery
- Light load drives where quiet, lube free operation matters
Mating Gears
Gears mesh when diametral pitch and pressure angle match. The SS3232 runs with any 32 DP, 2 degree pressure angle gear, regardless of tooth count or manufacturer.
Cross Reference
The SS3232 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| McMaster-Carr | 6832K54 |
| Powerdrive | SS3232 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What gears mesh with the SS3232?
Any gear with a 32 diametral pitch and 2 degree pressure angle, in any tooth count, from any manufacturer.
Does the SS3232 replace the McMaster-Carr 6832K54?
Yes. Published interchange data crosses the SS3232 directly to the McMaster-Carr 6832K54, as well as Powerdrive SS3232. Verify dimensions and bore before ordering.
Does the SS3232 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
