TL20H150 Timing Pulley, 2 Teeth, H Pitch


Price:
$ 57.90

Description

TL20H150 Timing Pulley, 2 Teeth, H Pitch

The TL20H150 is a 2-tooth H (0.500 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 1.5 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 3F pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number TL20H150
Teeth 2
Pitch H (0.500 in trapezoidal)
For Belt Width 1.5 in
Pitch Diameter 3.1831 in
Outside Diameter 3.1291 in
Flange Diameter 3.256 in
Bore Accepts 1215 bushing (not included)
Face Width 1.812 in
Overall Length 1.812 in
Construction Taper Lock Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 2.244 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The TL20H150 runs H (0.500 in trapezoidal) belts in 1.5 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The TL20H150 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® TL20H150-1210
Martin TB20H150
Gates® TL20H150
TB Woods® TL20H150
Mitsuboshi TL20H150-1215
Jason Industrial TL20H150
Optibelt TB 20-H-150
Masterdrive P20H150-1210
Ametric 20 H 150 TL
Powerdrive TL20H150

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the TL20H150 pulley?

H (0.500 in trapezoidal) timing belts in 1.5 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the TL20H150 replace the Dodge TL20H150-1210?

Yes. Published interchange data crosses the TL20H150 directly to the Dodge TL20H150-1210, as well as Martin TB20H150, Gates TL20H150, TB Woods TL20H150. Verify dimensions and bore before ordering.

Does the TL20H150 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on TL20H150?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
