TL20L050-1108 Timing Pulley, 2 Teeth, L Pitch


Price:
$ 33.70

Description

TL20L050-1108 Timing Pulley, 2 Teeth, L Pitch

The TL20L050-1108 is a 2-tooth L (0.375 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from steel with a black oxide finish, built for 0.5 in wide belts. Machined from solid stock, never sintered or powdered metal.

$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.

Specifications

Type 8F pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number TL20L050-1108
Teeth 2
Pitch L (0.375 in trapezoidal)
For Belt Width 0.5 in
Pitch Diameter 2.3873 in
Outside Diameter 2.3573 in
Flange Diameter 2.625 in
Bore Accepts 1108 bushing (not included)
Face Width 0.75 in
Overall Length 0.875 in
Construction Taper Lock Hub
Flange Material Steel
Material Steel (no sintered or powdered metal)
Finish Black Oxide
Weight 0.608 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The TL20L050-1108 runs L (0.375 in trapezoidal) belts in 0.5 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The TL20L050-1108 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® TL20L050-1108
Gates® TL20L050
Mitsuboshi TL20L050-1108
Optibelt TB 20-L-050
Masterdrive P20L050-1108
Ametric 20 L 050 TL.1108
Powerdrive TL20L050-1108

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the TL20L050-1108 pulley?

L (0.375 in trapezoidal) timing belts in 0.5 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the TL20L050-1108 replace the Dodge TL20L050-1108?

Yes. Published interchange data crosses the TL20L050-1108 directly to the Dodge TL20L050-1108, as well as Gates TL20L050, Mitsuboshi TL20L050-1108, Optibelt TB 20-L-050. Verify dimensions and bore before ordering.

Does the TL20L050-1108 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on TL20L050-1108?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358
