TL30H100 Timing Pulley, 3 Teeth, H Pitch
The TL30H100 is a 3-tooth H (0.500 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 1 in wide belts. Machined from solid stock, never sintered or powdered metal.
Specifications

Dimension key for this construction type. Values for this part number are in the table below.
| Specification | Value |
|---|---|
| Part Number | TL30H100 |
| Teeth | 3 |
| Pitch | H (0.500 in trapezoidal) |
| For Belt Width | 1 in |
| Pitch Diameter | 4.7746 in |
| Outside Diameter | 4.7206 in |
| Flange Diameter | 5 in |
| Bore | Accepts 2012 bushing (not included) |
| Face Width | 1.312 in |
| Overall Length | 1.312 in |
| Construction | Taper Lock Hub |
| Flange Material | Steel |
| Material | Ductile Iron (no sintered or powdered metal) |
| Finish | Black Oxide |
| Weight | 4.33 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- Instrumentation, office equipment, and precision positioning drives
- 3D printers and desktop CNC equipment
- Robotics, medical devices, and packaging machinery
Belt Compatibility
The TL30H100 runs H (0.500 in trapezoidal) belts in 1 in width. The pitch is standardized, so belt and pulley brands can be mixed.
Cross Reference
The TL30H100 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| Dodge® | TL30H100-2012 |
| Martin | TB30H100 |
| Gates® | TL30H100 |
| TB Woods® | TL30H100 |
| Mitsuboshi | TL30H100-2012 |
| Jason Industrial | TL30H100 |
| Optibelt | TB 30-H-100 |
| Masterdrive | P30H100-2012 |
| Ametric | 30 H 100 TL |
| Powerdrive | TL30H100 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
