TL30H200 Timing Pulley, 3 Teeth, H Pitch


Price:
$ 121.46

Description

TL30H200 Timing Pulley, 3 Teeth, H Pitch

The TL30H200 is a 3-tooth H (0.500 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 2 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 2F pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number TL30H200
Teeth 3
Pitch H (0.500 in trapezoidal)
For Belt Width 2 in
Pitch Diameter 4.7746 in
Outside Diameter 4.7206 in
Flange Diameter 5 in
Bore Accepts 2012 bushing (not included)
Face Width 2.344 in
Overall Length 2.344 in
Construction Taper Lock Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 6.717 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The TL30H200 runs H (0.500 in trapezoidal) belts in 2 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The TL30H200 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® TL30H200-2012
Martin TB30H200
Gates® TL30H200
TB Woods® TL30H200
Mitsuboshi TL30H200-2012
Jason Industrial TL30H200
Optibelt TB 30-H-200
Masterdrive P30H200-2012
Ametric 30 H 200 TL
Powerdrive TL30H200

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the TL30H200 pulley?

H (0.500 in trapezoidal) timing belts in 2 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the TL30H200 replace the Dodge TL30H200-2012?

Yes. Published interchange data crosses the TL30H200 directly to the Dodge TL30H200-2012, as well as Martin TB30H200, Gates TL30H200, TB Woods TL30H200. Verify dimensions and bore before ordering.

Does the TL30H200 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on TL30H200?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
