TL36L050 Timing Pulley, 36 Teeth, L Pitch


Price:
$ 64.93

Description

TL36L050 Timing Pulley, 36 Teeth, L Pitch

The TL36L050 is a 36-tooth L (0.375 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from ductile iron with a black oxide finish, built for 0.5 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 8F pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number TL36L050
Teeth 36
Pitch L (0.375 in trapezoidal)
For Belt Width 0.5 in
Pitch Diameter 4.2972 in
Outside Diameter 4.2672 in
Flange Diameter 4.52 in
Bore Accepts 1610 bushing (not included)
Face Width 0.75 in
Overall Length 1 in
Construction Taper Lock Hub
Flange Material Steel
Material Ductile Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 2.313 lb
Country of Origin United States. ISO 9001:2015 certified manufacturing.

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The TL36L050 runs L (0.375 in trapezoidal) belts in 0.5 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The TL36L050 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® TL36L050-1610
TB Woods® TL36L050
Mitsuboshi TL36L050-1610
Jason Industrial TL36L050
Optibelt TB 36-L-050
Ametric 36 L 050 TL
Powerdrive TL36L050

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the TL36L050 pulley?

L (0.375 in trapezoidal) timing belts in 0.5 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the TL36L050 replace the Dodge TL36L050-1610?

Yes. Published interchange data crosses the TL36L050 directly to the Dodge TL36L050-1610, as well as TB Woods TL36L050, Mitsuboshi TL36L050-1610, Jason Industrial TL36L050. Verify dimensions and bore before ordering.

Does the TL36L050 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on TL36L050?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
