TL72H150 Timing Pulley, 72 Teeth, H Pitch


Price:
$ 253.32

Description

TL72H150 Timing Pulley, 72 Teeth, H Pitch

The TL72H150 is a 72-tooth H (0.500 in trapezoidal) timing pulley. It mounts with an industry-standard bushing, sold separately, machined from cast iron with a black oxide finish, built for 1.5 in wide belts. Machined from solid stock, never sintered or powdered metal.

Specifications

Type 7 pulley construction dimension diagram

Dimension key for this construction type. Values for this part number are in the table below.

Specification Value
Part Number TL72H150
Teeth 72
Pitch H (0.500 in trapezoidal)
For Belt Width 1.5 in
Pitch Diameter 11.4592 in
Outside Diameter 11.4052 in
Bore Accepts 3020 bushing (not included)
Face Width 1.812 in
Overall Length 1.812 in
Construction Taper Lock Hub
Material Cast Iron (no sintered or powdered metal)
Finish Black Oxide
Weight 22.82 lb
Country of Origin China

Applications

  • Instrumentation, office equipment, and precision positioning drives
  • 3D printers and desktop CNC equipment
  • Robotics, medical devices, and packaging machinery

Belt Compatibility

The TL72H150 runs H (0.500 in trapezoidal) belts in 1.5 in width. The pitch is standardized, so belt and pulley brands can be mixed.

Cross Reference

The TL72H150 interchanges with these equivalent part numbers, per published manufacturer interchange data:

Manufacturer Equivalent Part Number
Dodge® TL72H150-3020
Gates® TL72H150
TB Woods® TL72H150
Mitsuboshi TL72H150-3020
Jason Industrial TL72H150
Optibelt TB 72-H-150
Masterdrive P72H150-3020
Ametric 72 H 150 TL
Powerdrive TL72H150

Always verify dimensions and bore size before substituting part numbers across manufacturers.

Buying in bulk? Save on volume.

Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.

Frequently Asked Questions

What belts fit the TL72H150 pulley?

H (0.500 in trapezoidal) timing belts in 1.5 in width from any manufacturer. The pitch is standardized, so belt and pulley brands can be mixed.

Does the TL72H150 replace the Dodge TL72H150-3020?

Yes. Published interchange data crosses the TL72H150 directly to the Dodge TL72H150-3020, as well as Gates TL72H150, TB Woods TL72H150, Mitsuboshi TL72H150-3020. Verify dimensions and bore before ordering.

Does the TL72H150 ship from Houston?

Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.

Need a quote on TL72H150?

Houston warehouse, same-day shipping on stock items.

Call (888) 203-2358

All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
