Description
Y3224 Gear, 24 Teeth, 32 DP, 2 Degree PA, Brass
The Y3224 is a 24-tooth, 32 diametral pitch gear with a 2 degree pressure angle and a 3/16 in minimum plain bore, brass.
$50 minimum order on drive components. Mix and match any pulleys, bushings, sheaves, sprockets, and accessories in your cart to reach the $50 minimum. Questions? Call (888) 203-2358.
Specifications
| Specification | Value |
|---|---|
| Part Number | Y3224 |
| Teeth | 24 |
| Diametral Pitch | 32 |
| Pressure Angle | 2 degrees |
| Pitch Diameter | 0.75 in |
| Outside Diameter | 0.812 in |
| Bore | 3/16 in minimum plain bore |
| Face Width | 0.188 in |
| Hub Diameter | 0.53 in |
| Overall Length | 0.438 in |
| Material | Brass (no sintered or powdered metal) |
| Weight | 0.041 lb |
| Country of Origin | United States. ISO 9001:2015 certified manufacturing. |
Applications
- Instrumentation and meter drive trains
- Packaging and labeling machinery
- Light load drives where quiet, lube free operation matters
Mating Gears
Gears mesh when diametral pitch and pressure angle match. The Y3224 runs with any 32 DP, 2 degree pressure angle gear, regardless of tooth count or manufacturer.
Cross Reference
The Y3224 interchanges with these equivalent part numbers, per published manufacturer interchange data:
| Manufacturer | Equivalent Part Number |
|---|---|
| McMaster-Carr | 7880K31 |
| Powerdrive | Y3224 |
Always verify dimensions and bore size before substituting part numbers across manufacturers.
Buying in bulk? Save on volume.
Multi-unit and OEM quantities qualify for volume discounts. Call or email for a quantity quote.
Frequently Asked Questions
What gears mesh with the Y3224?
Any gear with a 32 diametral pitch and 2 degree pressure angle, in any tooth count, from any manufacturer.
Does the Y3224 replace the McMaster-Carr 7880K31?
Yes. Published interchange data crosses the Y3224 directly to the McMaster-Carr 7880K31, as well as Powerdrive Y3224. Verify dimensions and bore before ordering.
Does the Y3224 ship from Houston?
Yes. Stock items ship same day from our Houston, Texas warehouse. Call (888) 203-2358 to confirm availability.
All third-party part numbers and trademarks referenced are the property of their respective owners. References are for compatibility identification only and do not imply affiliation or endorsement.
