BlackStar 40BS84 1 3/8 - 40 Pitch Finished Bore Sprocket - 84 Tooth - 1-3/8" Bore


Price:
$ 111.78

Description

The BlackStar 40BS84 1 3/8 is a 40 pitch Finished Bore roller chain sprocket with 84 teeth, precision manufactured from SAE 1045 steel and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket has a 1-3/8" bore with keyway and set screws and is ready for immediate installation.

Specifications
Part Number 40BS84 1 3/8
Chain Pitch 40
Number of Teeth 84
Bore Size 1-3/8"
Minimum Bore 3/4"
Maximum Bore 1-1/2"
Bore Type Finished Bore (Keyway + Set Screws)
Hub Style Finished Bore
Strand Count Single
Material Steel
Outside Diameter 13.66"
Pitch Diameter 13.372"
Approx. Weight 13.84 lbs
BlackStar 40BS84 1 3/8 Sprocket Spec Sheet

Cross-references: Browning H40B84, Martin 40BS84, Boston Gear RS40B84
