BlackStar D35G15H - Double Strand 35 Pitch QD Sprocket - 15 Tooth


Price:
$ 18.47

Description

The BlackStar D35G15H is a 35 pitch double strand QD roller chain sprocket with 15 teeth, precision manufactured from SAE 1045 steel and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket requires a QD Bushing (sold separately).

Specifications
Part Number D35G15H
Chain Pitch 35
Number of Teeth 15
Bore Type QD
Hub Style QD
Bushing Required QD Bushing
Strand Count Double
Material Steel
Outside Diameter 1.99"
Pitch Diameter 1.804"
Approx. Weight 0.56 lbs
BlackStar D35G15H Sprocket Spec Sheet

Bushing Required

This sprocket requires a QD Bushing to mount to your shaft. The bushing is sold separately and allows you to match the sprocket to your exact shaft diameter.

Shop Bushings

BlackStar QD Bushing Spec Sheet

Compatible Components

Matched Roller Chain

Shop all 24 matched options ›

Matched Roller Chain

Shop all 24 matched options ›

Matched Roller Chain

Shop all 24 matched options ›

Not sure what fits? Call (888) 203-2358 and we will match it from the Houston warehouse.
