BlackStar D80E32H - Double Strand 80 Pitch QD Sprocket - 32 Tooth


Price:
$ 294.52

Description

The BlackStar D80E32H is a 80 pitch double strand QD roller chain sprocket with 32 teeth, precision manufactured from SAE 1045 steel and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket requires a QD Type E Bushing (sold separately).

Specifications
Part Number D80E32H
Chain Pitch 80
Number of Teeth 32
Bore Type QD
Hub Style QD
Bushing Required QD Type E Bushing
Strand Count Double
Material Steel
Outside Diameter 10.75"
Pitch Diameter 10.202"
Approx. Weight 1.00001 lbs
BlackStar D80E32H Sprocket Spec Sheet

Bushing Required

This sprocket requires a QD Type E Bushing to mount to your shaft. The bushing is sold separately and allows you to match the sprocket to your exact shaft diameter.

Shop Bushings

BlackStar QD Type E Bushing Spec Sheet

Cross-references: Browning D80E32, Martin D80E32
