BlackStar D80F96 - Double Strand 80 Pitch QD Sprocket - 96 Tooth


Price:
$ 3,016.12

Description

The BlackStar D80F96 is a 80 pitch double strand QD roller chain sprocket with 96 teeth, precision manufactured from SAE 1045 steel and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket requires a QD Type SF Bushing (sold separately).

Specifications
Part Number D80F96
Chain Pitch 80
Number of Teeth 96
Bore Type QD
Hub Style QD
Bushing Required QD Type SF Bushing
Strand Count Double
Material Steel
Outside Diameter 31.15"
Pitch Diameter 30.563"
Approx. Weight 245.000 lbs
BlackStar D80F96 Sprocket Spec Sheet

Bushing Required

This sprocket requires a QD Type SF Bushing to mount to your shaft. The bushing is sold separately and allows you to match the sprocket to your exact shaft diameter.

Shop Bushings

BlackStar QD Type SF Bushing Spec Sheet

Cross-references: Browning D80F96, Martin D80F96
