BlackStar DS40ATL23H - Double-Single 40 Pitch Taper Lock Sprocket - 23 Tooth


Price:
$ 46.66

Description

The BlackStar DS40ATL23H is a 40 pitch double-single strand Taper Lock roller chain sprocket with 23 teeth, precision manufactured from SAE 1045 steel and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket requires a Taper Lock Bushing (sold separately).

Specifications
Part Number DS40ATL23H
Chain Pitch 40
Number of Teeth 23
Bore Type Plain Bore
Hub Style Taper Lock
Bushing Required Taper Lock Bushing
Strand Count Double-Single
Material Steel
Outside Diameter 3.94"
Pitch Diameter 3.672"
Approx. Weight 1.700 lbs
BlackStar DS40ATL23H Sprocket Spec Sheet

Bushing Required

This sprocket requires a Taper Lock Bushing to mount to your shaft. The bushing is sold separately and allows you to match the sprocket to your exact shaft diameter.

Shop Bushings

BlackStar Taper Lock Bushing Spec Sheet

Cross-references: Martin D40TB23, Browning D40TB23
