BlackStar H120BS14 2 3/4 K2S - 120 Pitch Finished Bore Sprocket - 14 Tooth - 2-3/4" Bore


Price:
$ 169.13

Description

The BlackStar H120BS14 2 3/4 K2S is a 120 pitch Finished Bore roller chain sprocket with 14 teeth, precision manufactured from SAE 1045 steel with induction-hardened teeth for extended wear life and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket has a 2-3/4" bore with keyway and set screws and is ready for immediate installation.

Specifications
Part Number H120BS14 2 3/4 K2S
Chain Pitch 120
Number of Teeth 14
Bore Size 2-3/4"
Minimum Bore 1-3/8"
Maximum Bore 3-1/4"
Bore Type Finished Bore (Keyway + Set Screws)
Hub Style Finished Bore
Strand Count Single
Material Steel
Hardened Teeth Yes
Outside Diameter 7.47"
Pitch Diameter 6.741"
Approx. Weight 14.4 lbs
BlackStar H120BS14 2 3/4 K2S Sprocket Spec Sheet

Cross-references: Martin 120BS14, Browning H120B14
