BlackStar H40A30 3/4 - 40 Pitch A-Plate Sprocket - 30 Tooth - 3/4" Bore


Price:
$ 25.47

Description

The BlackStar H40A30 3/4 is a 40 pitch A-Plate roller chain sprocket with 30 teeth, precision manufactured from SAE 1045 steel with induction-hardened teeth for extended wear life and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket has a 3/4" bore and is ready for immediate installation.

Specifications
Part Number H40A30 3/4
Chain Pitch 40
Number of Teeth 30
Bore Size 3/4"
Bore Type Plain Bore
Hub Style A-Plate
Strand Count Single
Material Steel
Hardened Teeth Yes
Outside Diameter 5.06"
Pitch Diameter 4.783"
Approx. Weight 1.26 lbs
BlackStar H40A30 3/4 Sprocket Spec Sheet

Cross-references: Browning 40A30, Martin 40A30, Boston Gear 40A30
