Gates 2/7M1120JB Polyflex JB Belts

Save $ 26.24

Price:
$ 87.48 $ 113.72

Free 3D CAD Model

Download this part's model from the Gates 3D CAD Library in 150+ formats, including SolidWorks, Inventor, CATIA and Creo.

Part number: 2/7M1120JB
Open Gates 3D CAD Library

On the Gates page, click Gates 3D CAD Library, then paste the part number into the search bar.

Description

The Gates 2/7M1120JB is a Polyflex JB joined V-belt: two 60° polyurethane strands cast as one band for added stability on high-speed drives.

Each strand is 7M section (7 mm top width) with polyester tensile cords. The joined construction keeps multi-strand drives running smoothly at shaft speeds where individual belts can turn over or whip.

Specifications

Belt Type Polyflex JB Joined V-Belt (60° polyurethane)
Section 7M-JB
Strands 2
Top Width per Strand 7 mm
Strand Spacing 8.50 mm
Height 5.33 mm
Effective Length (nominal) 1120 mm (44.1 in)
Tensile Cords Polyester
Color Black
Temperature Range -65°F to 185°F (-54°C to 85°C)

In stock and ready to ship from Texas Belting & Supply.
