LAIE15-12-284TC - Louis Allis, IEEE 841 Motor


Price:
$ 3,267.73

Description

LAIE15-12-284TC - Louis Allis, IEEE 841 Motor

The LAIE15-12-284TC is a 15 hp, 1200 rpm, 3-phase, 460v, 284tc frame, tefc louis allis, ieee 841 motor for industrial machinery and oem equipment. TEFC enclosure, 1.25 service factor.

Specifications

Specification Value
Part Number LAIE15-12-284TC
Horsepower (HP) 15
Speed (RPM) 1200
Phase Three-Phase
Voltage 460
Frequency 60 HZ
NEMA Frame 284TC
Enclosure TEFC
Service Factor 1.25
Full-Load Efficiency (%) 91.7
Full-Load Amps 18.4
Insulation Class Class H
Mounting C-Face with Feet
Ingress Protection IP55
Weight (lbs) 443
Warranty Five Year

Applications

  • Industrial machinery and OEM equipment
  • Fans, blowers, and pumps
  • Conveyors and material handling
  • Direct replacement for failed motors

Documentation & Downloads

Frequently Asked Questions

What is the LAIE15-12-284TC used for?

The LAIE15-12-284TC is a 15 hp, 1200 rpm, 3-phase, 460v, 284tc frame, tefc louis allis, ieee 841 motor used for industrial machinery and oem equipment and similar loads.

What frame is the LAIE15-12-284TC?

The LAIE15-12-284TC uses a NEMA 284TC frame. Confirm shaft diameter, mounting (base or C-face), and bolt pattern against your existing motor before ordering a replacement.

What voltage does the LAIE15-12-284TC run on?

The LAIE15-12-284TC is rated 460V, 3-Phase at 60 HZ. Verify supply voltage and connection against the motor nameplate.

How fast does the LAIE15-12-284TC ship?

Most in-stock units of the LAIE15-12-284TC ship the same or next business day; non-stock items vary. Call (888) 203-2358 to confirm availability and freight.

Helpful guides: NEMA frame size chart · How to read a motor nameplate
