LAIE400-36-586-7 — Louis Allis, IEEE 841 Motor


Price:
$ 33,235.69

Description

LAIE400-36-586-7 — Louis Allis, IEEE 841 Motor

The LAIE400-36-586-7 is a 400 hp, 3600 rpm, 3-phase, 460v, 586/7 frame, tefc louis allis, ieee 841 motor for industrial machinery and oem equipment. TEFC enclosure, 1.15 service factor.

Specifications

Specification Value
Part Number LAIE400-36-586-7
Horsepower (HP) 400
Speed (RPM) 3600
Phase Three-Phase
Voltage 460
Frequency 60 HZ
NEMA Frame 586/7
Enclosure TEFC
Service Factor 1.15
Full-Load Efficiency (%) 95.8
Full-Load Amps 425.3
Insulation Class Class H
Mounting Rigid Base
Ingress Protection IP55
Weight (lbs) 3474
Warranty Five Year

Applications

  • Industrial machinery and OEM equipment
  • Fans, blowers, and pumps
  • Conveyors and material handling
  • Direct replacement for failed motors

Documentation & Downloads

Frequently Asked Questions

What is the LAIE400-36-586-7 used for?

The LAIE400-36-586-7 is a 400 hp, 3600 rpm, 3-phase, 460v, 586/7 frame, tefc louis allis, ieee 841 motor used for industrial machinery and oem equipment and similar loads.

What frame is the LAIE400-36-586-7?

The LAIE400-36-586-7 uses a NEMA 586/7 frame. Confirm shaft diameter, mounting (base or C-face), and bolt pattern against your existing motor before ordering a replacement.

What voltage does the LAIE400-36-586-7 run on?

The LAIE400-36-586-7 is rated 460V, 3-Phase at 60 HZ. Verify supply voltage and connection against the motor nameplate.

How fast does the LAIE400-36-586-7 ship?

Most in-stock units of the LAIE400-36-586-7 ship the same or next business day; non-stock items vary. Call (888) 203-2358 to confirm availability and freight.
