LAM2-12-184TC — Louis Allis, Premium Efficient Motor


Price:
$ 657

Description

LAM2-12-184TC — Louis Allis, Premium Efficient Motor

The LAM2-12-184TC is a 2 hp, 1200 rpm, 3-phase, 230/460v, 184tc frame, tefc louis allis, premium efficient motor for industrial machinery and oem equipment. TEFC enclosure, 1.25 service factor.

Specifications

Specification Value
Part Number LAM2-12-184TC
Horsepower (HP) 2
Speed (RPM) 1200
Phase Three-Phase
Voltage 230/460
Frequency 60 HZ
NEMA Frame 184TC
Enclosure TEFC
Service Factor 1.25
Insulation Class Class F
Mounting C-Face with Feet
Ingress Protection IP55
Warranty Three Year

Applications

  • Industrial machinery and OEM equipment
  • Fans, blowers, and pumps
  • Conveyors and material handling
  • Direct replacement for failed motors

Documentation & Downloads

Frequently Asked Questions

What is the LAM2-12-184TC used for?

The LAM2-12-184TC is a 2 hp, 1200 rpm, 3-phase, 230/460v, 184tc frame, tefc louis allis, premium efficient motor used for industrial machinery and oem equipment and similar loads.

What frame is the LAM2-12-184TC?

The LAM2-12-184TC uses a NEMA 184TC frame. Confirm shaft diameter, mounting (base or C-face), and bolt pattern against your existing motor before ordering a replacement.

What voltage does the LAM2-12-184TC run on?

The LAM2-12-184TC is rated 230/460V, 3-Phase at 60 HZ. Verify supply voltage and connection against the motor nameplate.

How fast does the LAM2-12-184TC ship?

Most in-stock units of the LAM2-12-184TC ship the same or next business day; non-stock items vary. Call (888) 203-2358 to confirm availability and freight.

Need a quote on LAM2-12-184TC?

Most in-stock items ship same-day — call to confirm availability and freight.

Call (888) 203-2358
