Lynx C2120H RIV 10' - Extended Pitch Chain 10ft Reel


Price:
$ 333.28

Description

âš¡ Complete Your Order

Chain reels do not include connecting hardware. Add a matching connecting link from the same C2120H family to join the chain ends after installation:

CONNECTING LINKS:
C2120H C/P C/L
OFFSET LINKS:
C2120H O/L

The Lynx C2120H RIV 10' is a 10-foot reel of extended pitch chain for industrial power transmission applications. Includes pre-lubed chain and 1 (one) connecting link. Sold as a complete reel, ready for installation.

Specifications

Chain Size 2120
Series C2120 Series
Number of strands 1
Material Steel
Pitch 3.00
Roller Diameter 0.875
Pin Diameter 0.437
Pin Length 2.11
Link Plate Height 1.41
Plate Thickness 0.219
Width Between Inner Plates 0.993
Average Tensile Strength (lbs.) 36170
Max Working Load (lbs.) 4811
Minimum Tensile Strength (lbs.) 28864
Included Pre-Lubed Chain and 1 (one) Connecting Link.
Cottered Pin-length (Max) 2.26
Weight per Foot 3.5 lbs/ft
Total Reel Weight 35 lbs (10 ft × 3.5 lbs/ft)
GTIN 192056073159
