Lynx HD50HP RIV 10' - Roller Chain 10ft Reel


Price:
$ 181.02

Description

âš¡ Complete Your Order

Chain reels do not include connecting hardware. Add a matching connecting link from the same HD50HP family to join the chain ends after installation:

CONNECTING LINKS:
HD50HP C/L
OFFSET LINKS:
HD50HP O/L

The Lynx HD50HP RIV 10' is a 10-foot reel of roller chain for industrial power transmission applications. Includes pre-lubed chain and 1 (one) connecting link. Sold as a complete reel, ready for installation.

Specifications

Chain Size 50
Series HD50 Series
Number of strands 1
Material Steel
Pitch 0.63
Roller Diameter 0.4
Pin Diameter 0.277
Pin Length 0.81
Link Plate Height 0.59
Plate Thickness 0.08
Width Between Inner Plates 0.375
Average Tensile Strength (lbs.) 5081
Max Working Load (lbs.) 652
Minimum Tensile Strength (lbs.) 4545
Lubrication Info Prelubed
Included Pre-Lubed Chain and 1 (one) Connecting Link.
Hollow Pin Inside Diameter 0.202
Weight per Foot 0.7 lbs/ft
Total Reel Weight 7 lbs (10 ft × 0.7 lbs/ft)
