Description
Chain reels do not include connecting hardware. Add a matching connecting link from the same XD100-6 family to join the chain ends after installation:
XD100-6 C/P C/L
XD100-6 O/L
This chain mates with #100 (1-1/4") ANSI standard sprockets. Browse our BlackStar selection in this pitch.
View #100 Sprockets →The Lynx XD100-6 RIV 5' is a 5-foot reel of xd extreme duty chain for industrial power transmission applications. Includes pre-lubed chain and 1 (one) connecting link. Sold as a complete reel, ready for installation.
Specifications
| Chain Size | 100 |
| Series | XD100-6 Series |
| Number of strands | 6 |
| Material | Steel |
| Pitch | 1.250 |
| Roller Diameter | 0.750 |
| Pin Diameter | 0.375 |
| Link Plate Height | 1.190 |
| Width Between Inner Plates | 0.750 |
| Lubrication Info | Prelubed |
| Included | Pre-Lubed Chain and 1 (one) Connecting Link. |
| Weight per Foot | 15.2 lbs/ft |
| Total Reel Weight | 76 lbs (5 ft × 15.2 lbs/ft) |
| GTIN | 192056076839 |
