Lynx XD100H RIV 50' - XD Extreme Duty Chain 50ft Reel


Price:
$ 2,348.11

Description

⚡ Complete Your Order

Chain reels do not include connecting hardware. Add a matching connecting link from the same XD100H family to join the chain ends after installation:

CONNECTING LINKS:
XD100H C/P C/L
OFFSET LINKS:
XD100H O/L
⚙ Compatible Sprockets

This chain mates with #100 (1-1/4") ANSI standard sprockets. Browse our BlackStar selection in this pitch.

View #100 Sprockets →

The Lynx XD100H RIV 50' is a 50-foot reel of xd extreme duty chain for industrial power transmission applications. Sold as a complete reel, ready for installation.

Specifications

Chain Size 100
Series XD100H Series
Number of strands 1
Material Steel
Pitch 1.250
Roller Diameter 0.750
Pin Diameter 0.375
Pin Length 1.190
Link Plate Height 0.189
Width Between Inner Plates 0.750
Average Tensile Strength (lbs.) 26455
Max Working Load (lbs.) 6172
Minimum Tensile Strength (lbs.) 23799
Lubrication Info Prelubed
Weight per Foot 3.1 lbs/ft
Total Reel Weight 155 lbs (50 ft × 3.1 lbs/ft)
GTIN 192056076877
