Description
Chain reels do not include connecting hardware. Add a matching connecting link from the same XD50 family to join the chain ends after installation:
XD50 S/C C/L
XD50 O/L
The Lynx XD50 RIV 100' is a 100-foot reel of xd extreme duty chain for industrial power transmission applications. Includes pre-lubed chain and 1 (one) connecting link. Sold as a complete reel, ready for installation.
Specifications
| Chain Size | 50 |
| Series | XD50 Series |
| Number of strands | 1 |
| Material | Steel |
| Pitch | 0.630 |
| Roller Diameter | 0.400 |
| Pin Diameter | 0.200 |
| Pin Length | 0.800 |
| Link Plate Height | 0.590 |
| Plate Thickness | 0.079 |
| Width Between Inner Plates | 0.376 |
| Average Tensile Strength (lbs.) | 7160 |
| Max Working Load (lbs.) | 1389 |
| Minimum Tensile Strength (lbs.) | 5952 |
| Lubrication Info | Prelubed |
| Included | Pre-Lubed Chain and 1 (one) Connecting Link. |
| Weight per Foot | 0.7 lbs/ft |
| Total Reel Weight | 70 lbs (100 ft × 0.7 lbs/ft) |
| GTIN | 192056077591 |
Compatible Components
Matched Sprockets
- 50A15 Roller Chain Sprocket, #50 Chain, 15 Teeth, A Hub
- 50A20 Roller Chain Sprocket, #50 Chain, 2 Teeth, A Hub
- 50A28 Roller Chain Sprocket, #50 Chain, 28 Teeth, A Hub
- 50A30 Roller Chain Sprocket, #50 Chain, 3 Teeth, A Hub
Shop all 2795 matched options ›
Connecting Links
- Lynx HD50 C/P C/L - Connecting Link
- Lynx HD50 C/P C/L - Connecting Link
- Lynx HD50 S/C C/L - Connecting Link
- Lynx HD50 S/C C/L - Connecting Link
Shop all 28 matched options ›
Offset Links
- Lynx HD50 O/L - Offset Link
- Lynx HD50 O/L - Offset Link
- Lynx HD50-2 O/L - Offset Link
- Lynx HD50-2 O/L - Offset Link
Shop all 24 matched options ›
Matched Sprockets
- 50A15 Roller Chain Sprocket, #50 Chain, 15 Teeth, A Hub
- 50A20 Roller Chain Sprocket, #50 Chain, 2 Teeth, A Hub
- 50A28 Roller Chain Sprocket, #50 Chain, 28 Teeth, A Hub
- 50A30 Roller Chain Sprocket, #50 Chain, 3 Teeth, A Hub
Shop all 2795 matched options ›
Connecting Links
- Lynx HD50 C/P C/L - Connecting Link
- Lynx HD50 C/P C/L - Connecting Link
- Lynx HD50 S/C C/L - Connecting Link
- Lynx HD50 S/C C/L - Connecting Link
Shop all 28 matched options ›
Offset Links
- Lynx HD50 O/L - Offset Link
- Lynx HD50 O/L - Offset Link
- Lynx HD50-2 O/L - Offset Link
- Lynx HD50-2 O/L - Offset Link
Shop all 24 matched options ›
Not sure what fits? Call (888) 203-2358 and we will match it from the Houston warehouse.
