PESS184TC2M-6-A — Washdown Stainless Steel Motor


Price:
$ 1,422.12

Description

PESS184TC2M-6-A — Washdown Stainless Steel Motor

The PESS184TC2M-6-A is a 2 hp, 1200 rpm, 3-phase, 230/460v, 184tc frame, tefc washdown stainless steel motor for food and beverage processing. TEFC enclosure, 1.15 service factor.

Specifications

Specification Value
Part Number PESS184TC2M-6-A
Horsepower (HP) 2
Speed (RPM) 1200
Phase Three-Phase
Voltage 230/460
Frequency 60 HZ
NEMA Frame 184TC
Enclosure TEFC
Service Factor 1.15
Insulation Class Class F
Mounting C-Face with Feet
Ingress Protection IP66

Applications

  • Food and beverage processing
  • Sanitary and w, high-pressure washdown areas
  • Corrosive and wet environments
  • Pharma and packaging lines

Frequently Asked Questions

What is the PESS184TC2M-6-A used for?

The PESS184TC2M-6-A is a 2 hp, 1200 rpm, 3-phase, 230/460v, 184tc frame, tefc washdown stainless steel motor used for food and beverage processing and similar loads.

What frame is the PESS184TC2M-6-A?

The PESS184TC2M-6-A uses a NEMA 184TC frame. Confirm shaft diameter, mounting (base or C-face), and bolt pattern against your existing motor before ordering a replacement.

What voltage does the PESS184TC2M-6-A run on?

The PESS184TC2M-6-A is rated 230/460V, 3-Phase at 60 HZ. Verify supply voltage and connection against the motor nameplate.

How fast does the PESS184TC2M-6-A ship?

Most in-stock units of the PESS184TC2M-6-A ship the same or next business day; non-stock items vary. Call (888) 203-2358 to confirm availability and freight.

Helpful guides: ODP vs TEFC enclosure guide · How to read a motor nameplate
