Turner 2-Bolt Flange Block - 15/16" Bore, Eccentric Locking Collar


Price:
$ 24.71

Description

The Turner HCFT205 15 is a 2-bolt flange block mounted bearing unit with a 15/16" bore. It features a HC series insert with eccentric locking in a cast iron housing. Pre-lubricated and ready for installation.

Product Specifications

Bore Size 15/16"
Housing Style 2-Bolt Flange Block
Insert Series HC
Shaft Attachment Eccentric
Housing Material Cast Iron
Bearing Type Ball Bearing
Dynamic Load Rating 3,156 lbs
Static Load Rating 1,810 lbs
Limiting Speed 6000 RPM
Bolt Size 3/8"
Duty Level Normal
Part Number HCFT205 15

Series Specifications

Dimensional drawing for Turner HCFT205 15

Insert Specifications

Turner HC series bearing insert specifications
