Turner 2-Bolt Flange Block - 17mm Bore, Eccentric Locking Collar


Price:
$ 31.45

Description

The Turner HCWFT203 17MM is a 2-bolt flange block mounted bearing unit with a 17mm bore. It features a HCW series insert with eccentric locking in a cast iron housing. Pre-lubricated and ready for installation.

Product Specifications

Bore Size 17mm
Housing Style 2-Bolt Flange Block
Insert Series HCW
Shaft Attachment Eccentric
Housing Material Cast Iron
Bearing Type Ball Bearing
Dynamic Load Rating 2,147 lbs
Static Load Rating 1,075 lbs
Limiting Speed 6000 RPM
Bolt Size 3/8"
Duty Level Normal
Part Number HCWFT203 17MM

Series Specifications

Dimensional drawing for Turner HCWFT203 17MM

Insert Specifications

Turner HCW series bearing insert specifications
