Turner 2-Bolt Flange Block - 3/4" Bore, Set Screw Locking Collar


Price:
$ 20.22

Description

The Turner SBFT204 12 is a 2-bolt flange block mounted bearing unit with a 3/4" bore. It features a SB series insert with set screw locking in a cast iron housing. Pre-lubricated and ready for installation.

Product Specifications

Bore Size 3/4"
Housing Style 2-Bolt Flange Block
Insert Series SB
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Dynamic Load Rating 2,882 lbs
Static Load Rating 1,495 lbs
Limiting Speed 6000 RPM
Bolt Size 3/8"
Duty Level Light
Part Number SBFT204 12

Series Specifications

Dimensional drawing for Turner SBFT204 12

Insert Specifications

Turner SB series bearing insert specifications
