Turner 4-Bolt Flange Block - 1-3/16" Bore, Set Screw Locking Collar


Price:
$ 34.44

Description

The Turner UCF207 19 is a 4-bolt flange block mounted bearing unit with a 1-3/16" bore. It features a UC series insert with set screw locking in a cast iron housing. Pre-lubricated and ready for installation.

Product Specifications

Bore Size 1-3/16"
Housing Style 4-Bolt Flange Block
Insert Series UC
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Dynamic Load Rating 5,775 lbs
Static Load Rating 3,498 lbs
Limiting Speed 4500 RPM
Bolt Size 1/2"
Duty Level Normal
Part Number UCF207 19

Series Specifications

Dimensional drawing for Turner UCF207 19

Insert Specifications

Turner UC series bearing insert specifications
