Turner 4-Bolt Flange Block - 1-3/8" Bore, Set Screw Locking Collar - L3 Heavy-Duty Seal


Price:
$ 41.18

Description

The Turner UCF207 22 L3 is a 4-bolt flange block mounted bearing unit with a 1-3/8" bore. It features a UC series insert with set screw locking in a cast iron housing. This unit includes enhanced sealing for extended service life.

Product Specifications

Bore Size 1-3/8"
Housing Style 4-Bolt Flange Block
Insert Series UC
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Lubrication / Seal L3 Heavy-Duty
Dynamic Load Rating 5,775 lbs
Static Load Rating 3,498 lbs
Limiting Speed 4500 RPM
Bolt Size 1/2"
Duty Level Normal
Part Number UCF207 22 L3

Series Specifications

Dimensional drawing for Turner UCF207 22 L3

Insert Specifications

Turner UC series bearing insert specifications
