Turner 3-Bolt Flange Bracket - 1-1/2" Bore, Set Screw Locking Collar - L3 Heavy-Duty Seal


Price:
$ 55.41

Description

The Turner UCFBS208 24 L3 is a 3-bolt flange bracket mounted bearing unit with a 1-1/2" bore. It features a UC series insert with set screw locking in a cast iron housing. This unit includes enhanced sealing for extended service life.

Product Specifications

Bore Size 1-1/2"
Housing Style 3-Bolt Flange Bracket
Insert Series UC
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Lubrication / Seal L3 Heavy-Duty
Dynamic Load Rating 6,634 lbs
Static Load Rating 4,078 lbs
Limiting Speed 4000 RPM
Bolt Size 1/2"
Duty Level Normal
Part Number UCFBS208 24 L3

Series Specifications

Dimensional drawing for Turner UCFBS208 24 L3

Insert Specifications

Turner UC series bearing insert specifications
