Turner 4-Bolt Flange Cartridge - 12mm Bore, Set Screw Locking Collar - L3 Heavy-Duty Seal


Price:
$ 34.44

Description

The Turner UCFC201 12MM L3 is a 4-bolt flange cartridge mounted bearing unit with a 12mm bore. It features a UC series insert with set screw locking in a cast iron housing. This unit includes enhanced sealing for extended service life.

Product Specifications

Bore Size 12mm
Housing Style 4-Bolt Flange Cartridge
Insert Series UC
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Lubrication / Seal L3 Heavy-Duty
Dynamic Load Rating 2,147 lbs
Static Load Rating 1,075 lbs
Limiting Speed 6000 RPM
Bolt Size 3/8"
Duty Level Normal
Part Number UCFC201 12MM L3

Series Specifications

Dimensional drawing for Turner UCFC201 12MM L3

Insert Specifications

Turner UC series bearing insert specifications
