Turner 4-Bolt Flange Cartridge - 25 H4 DUCT Bore, Set Screw Locking Collar


Price:
$ 46.43

Description

The Turner UCFC208 25 H4 DUCT is a 4-bolt flange cartridge mounted bearing unit with a 25" bore. It features a UC series insert with set screw locking in a cast iron housing. Pre-lubricated and ready for installation.

Product Specifications

Bore Size 25"
Housing Style 4-Bolt Flange Cartridge
Insert Series UC
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Dynamic Load Rating 6,634 lbs
Static Load Rating 4,078 lbs
Limiting Speed 4000 RPM
Bolt Size 1/2"
Duty Level Normal
Part Number UCFC208 25 H4 DUCT

Series Specifications

Dimensional drawing for Turner UCFC208 25 H4 DUCT

Insert Specifications

Turner UC series bearing insert specifications
