Turner 4-Bolt Flange Cartridge - 2-3/16" Bore, Set Screw Locking Collar


Price:
$ 89.86

Description

The Turner UCFCS211 35 is a 4-bolt flange cartridge mounted bearing unit with a 2-3/16" bore. It features a UC series insert with set screw locking in a cast iron housing. Pre-lubricated and ready for installation.

Product Specifications

Bore Size 2-3/16"
Housing Style 4-Bolt Flange Cartridge
Insert Series UC
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Dynamic Load Rating 9,743 lbs
Static Load Rating 6,609 lbs
Limiting Speed 2500 RPM
Bolt Size 5/8"
Duty Level Normal
Part Number UCFCS211 35

Series Specifications

Dimensional drawing for Turner UCFCS211 35

Insert Specifications

Turner UC series bearing insert specifications
