Turner Medium-Duty Flange Cartridge - 2-1/2" Bore, Set Screw Locking Collar


Price:
$ 216.17

Description

The Turner UCFCSX13 40 is a medium-duty flange cartridge mounted bearing unit with a 2-1/2" bore. It features a UCX series insert with set screw locking in a cast iron housing. Pre-lubricated and ready for installation.

Product Specifications

Bore Size 2-1/2"
Housing Style Medium-Duty Flange Cartridge
Insert Series UCX
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Dynamic Load Rating 13,981 lbs
Static Load Rating 9,869 lbs
Limiting Speed 1700 RPM
Bolt Size 5/8"
Duty Level Medium
Part Number UCFCSX13 40

Series Specifications

Dimensional drawing for Turner UCFCSX13 40

Insert Specifications

Turner UCX series bearing insert specifications
