Turner 2-Bolt Flange Block - 30mm Bore, Set Screw Locking Collar - L3 Heavy-Duty Seal


Price:
$ 35.94

Description

The Turner UCFT206 30MM L3 is a 2-bolt flange block mounted bearing unit with a 30mm bore. It features a UC series insert with set screw locking in a cast iron housing. This unit includes enhanced sealing for extended service life.

Product Specifications

Bore Size 30mm
Housing Style 2-Bolt Flange Block
Insert Series UC
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Lubrication / Seal L3 Heavy-Duty
Dynamic Load Rating 4,377 lbs
Static Load Rating 2,569 lbs
Limiting Speed 5300 RPM
Bolt Size 1/2"
Duty Level Normal
Part Number UCFT206 30MM L3

Series Specifications

Dimensional drawing for Turner UCFT206 30MM L3

Insert Specifications

Turner UC series bearing insert specifications
