Turner Tapped Base Pillow Block - 2" Bore, Set Screw Locking Collar - L3 Heavy-Duty Seal


Price:
$ 77.13

Description

The Turner UCTB210 32 L3 is a tapped base pillow block mounted bearing unit with a 1/8" bore. It features a UC series insert with set screw locking in a cast iron housing. This unit includes enhanced sealing for extended service life.

Product Specifications

Bore Size 1/8"
Housing Style Tapped Base Pillow Block
Insert Series UC
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Lubrication / Seal L3 Heavy-Duty
Dynamic Load Rating 7,868 lbs
Static Load Rating 5,330 lbs
Limiting Speed 3000 RPM
Bolt Size 5/8"
Duty Level Normal
Part Number UCTB210 32 L3

Series Specifications

Dimensional drawing for Turner UCTB210 32 L3

Insert Specifications

Turner UC series bearing insert specifications
