Turner 4-Bolt Flange Block - 1/2" Bore, Set Screw Locking Collar


Price:
$ 24.71

Description

The Turner UCWF201 08 is a 4-bolt flange block mounted bearing unit with a 1/2" bore. It features a UCW series insert with set screw locking in a cast iron housing. Pre-lubricated and ready for installation.

Product Specifications

Bore Size 1/2"
Housing Style 4-Bolt Flange Block
Insert Series UCW
Shaft Attachment Set Screw
Housing Material Cast Iron
Bearing Type Ball Bearing
Dynamic Load Rating 2,147 lbs
Static Load Rating 1,075 lbs
Limiting Speed 6000 RPM
Bolt Size 3/8"
Duty Level Normal
Part Number UCWF201 08

Series Specifications

Dimensional drawing for Turner UCWF201 08

Insert Specifications

Turner UCW series bearing insert specifications
