Turner 2-Bolt Flange Block - 1-7/16" Bore, Tru-Loc Concentric Clamping Collar


Price:
$ 80.41

Description

The Turner UEFT207 23 is a 2-bolt flange block mounted bearing unit with a 1-7/16" bore. It features a UE series insert with tru-loc locking in a cast iron housing. Pre-lubricated and ready for installation.

Product Specifications

Bore Size 1-7/16"
Housing Style 2-Bolt Flange Block
Insert Series UE
Shaft Attachment Tru-Loc
Housing Material Cast Iron
Bearing Type Ball Bearing
Dynamic Load Rating 5,775 lbs
Static Load Rating 3,498 lbs
Limiting Speed 4500 RPM
Bolt Size 1/2"
Duty Level Normal
Part Number UEFT207 23

Series Specifications

Dimensional drawing for Turner UEFT207 23

Insert Specifications

Turner UE series bearing insert specifications
