Description
The Vortex VMRV-110-30-180TC is an IEC metric standard worm gear speed reducer with a 30:1 nominal ratio, a 110 mm (4.331") center distance, and a NEMA 180TC C-face input flange. Cast iron housing, hollow output bore for direct shaft mounting. This unit is the direct Vortex equivalent for the Motovario NMRV-110-30 reducer at matching motor frame, designed for replacement of European IEC metric worm gear reducers on existing OEM equipment in the 7.5 to 15 HP class.
Specifications
| Specification | Value |
|---|---|
| Part Number | Vortex VMRV-110-30-180TC |
| Series | Vortex VMRV-Series IEC Metric Worm Gear Reducer |
| Unit Size | VMRV-110 (IEC standard) |
| HP Class | 7.5 to 15 HP |
| Nominal Ratio | 30:1 |
| Center Distance | 110 mm (4.331") |
| Input Configuration | NEMA 180TC C-face input flange |
| Output Configuration | Hollow output bore (output shaft and flange accessories sold separately) |
| Output Orientation | Left and Right |
| Housing Material | Cast iron |
| Overall Dimensions | 252.50 × 155 × 295 mm (9.94" × 6.1" × 11.61") |
| Weight | 94.3 lbs (42.77 kg) |
| Lubrication | Synthetic gear oil charge, -20 to 200 deg F service range |
| GTIN | 192056255272 |
| Direct Cross-Reference | Motovario NMRV-110-30 (same IEC sizing) |
| Shipping | Texas Belting & Supply, Houston, TX |
About This Unit
The Vortex VMRV-110 follows the IEC metric worm gear standard, with center distance designated in millimeters and motor frames using NEMA C-face mounting. The cast iron housing provides corrosion resistance and appropriate strength for the 7.5 to 15 HP torque class. Synthetic gear oil supports service from minus 20 to 200 degrees Fahrenheit, suiting indoor, outdoor protected, and washdown applications.
This unit is the direct Vortex replacement for the Motovario NMRV-110-30 reducer, with full dimensional interchange at the same IEC size, ratio, and motor frame. It also cross-references to Bonfiglioli VF, SEW-Eurodrive S-Series, STM Italy RV/RT, and other IEC metric worm gear brands. Typical applications include conveyor drives, packaging machinery, mixers, and OEM equipment built to European metric standards.
Frequently Asked Questions
What does the Vortex VMRV-110-30-180TC replace?
This unit is the direct Vortex equivalent for Motovario NMRV-110-30 at NEMA 180TC motor frame. It also cross-references dimensionally to Bonfiglioli VF-110, SEW-Eurodrive S-Series at 110 mm center distance, STM Italy RV-110, and other IEC metric worm gear brands at the same size and ratio. Match motor frame designation (NEMA C-face vs IEC B5/B14) and output configuration when substituting.
What accessories do I need for the VMRV-110?
The VMRV-110 ships with a hollow output bore. Depending on your driven equipment, you may also need: an output flange (VMRV-110 OSF) to convert to flange-mount output, a single-ended solid output shaft (VMRV-110 OSS), a double-ended output shaft (VMRV-110 OSD), a cover (VMRV-110 CVR) for the unused output side, or a torque arm (VMRV-110 TA) when the unit is mounted directly on the driven shaft via the hollow bore. All accessories are sold separately.
Does the Vortex VMRV-110-30-180TC ship from Houston?
Yes. This part ships from Texas Belting and Supply's Houston, TX warehouse the same business day for orders placed before 3 PM Central time, subject to current inventory. Call (888) 203-2358 to confirm stock or request a complete drive package quote.
Questions about this Vortex VMRV-110-30-180TC?
Complete drive packages available (reducer plus accessories). Same-day shipping from Houston.
