BlackStar 100BS16 3 K2S - 100 Pitch Finished Bore Sprocket - 16 Tooth - 3" Bore


Price:
$ 78.25

Description

The BlackStar 100BS16 3 K2S is a 100 pitch Finished Bore roller chain sprocket with 16 teeth, precision manufactured from SAE 1045 steel and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket has a 3" bore with keyway and set screws and is ready for immediate installation.

Specifications
Part Number 100BS16 3 K2S
Chain Pitch 100
Number of Teeth 16
Bore Size 3"
Minimum Bore 1-7/16"
Maximum Bore 2-15/16"
Bore Type Finished Bore (Keyway + Set Screws)
Hub Style Finished Bore
Strand Count Single
Material Steel
Outside Diameter 7.03"
Pitch Diameter 6.408"
Approx. Weight 9.0 lbs
BlackStar 100BS16 3 K2S Sprocket Spec Sheet

Cross-references: Browning H100B16, Martin 100BS16, Boston Gear RS100B16
