Description
The BlackStar 100E60 is a 100 pitch QD roller chain sprocket with 60 teeth, precision manufactured from SAE 1045 steel and features machine-cut tooth profiles for smooth, reliable chain engagement. This sprocket requires a QD Type E Bushing (sold separately).
| Specifications | |
|---|---|
| Part Number | 100E60 |
| Chain Pitch | 100 |
| Number of Teeth | 60 |
| Maximum Bore | 3-1/2" |
| Bore Type | QD |
| Hub Style | QD |
| Bushing Required | QD Type E Bushing |
| Strand Count | Single |
| Material | Steel |
| Outside Diameter | 24.60" |
| Pitch Diameter | 23.884" |
| Approx. Weight | 74.0 lbs |

Bushing Required
This sprocket requires a QD Type E Bushing to mount to your shaft. The bushing is sold separately and allows you to match the sprocket to your exact shaft diameter.

Cross-references: Browning 100E60, Martin 100E60
